Our way to good software architecture

In this article, I wanted to share an experience of how we arrived at the architecture we are using now in our Android application and why we consider it well suited for our project. From my point of view, it is easier to describe what makes software design poor than list features that make it good. And to know what is poor software design one must have some experience with projects where the results were not very satisfying but the lessons learned were valuable. Therefore let me share some things I learned that stay on the way to good software architecture:

  • hard to add new functionality or feature:

    • there is no code to reuse for functionality that shares common traits with already implemented functionality and you are forced to copy existing code to implement a new feature

    • the only solution how to implement a feature is to rewrite existing code to fit your needs

    • it is easier to use a hack to implement a feature rather than find a place for the feature in the existing project structure

    • when you add a new code, you break existing functionality

    • it is hard for a team to work simultaneously on the same codebase

    • it is hard to read the code, even if only one developer works on code

  • hard to test added functionality:

    • you can’t isolate software units for tests

    • it is easier to test application manually as whole rather than write unit and integration tests for separate peace of software

As result writing and the testing code becomes more time consuming and more expensive.

Once we start to notice one of these things it is time to start to think about improving or introducing the architecture in our software. The architecture probably is not a big deal if you are building a 1000 line app or writing a prove of concept app, but since our project is neither of those cases, it was clear from the very beginning that we need a solid design for our application. I already wrote about the technologies we decided to use and how we arrived at those particular conclusions. And now when we are close to the finish we can look back and see whether our choices paid off. But first let me make clear, it is not possible to make a perfect design with the first time unless you already have developed an application with very similar user requirements and even then you should revise the technologies used. And that was one of the first lessons we learned about the app’s architecture in our project. Once we noticed that adding new features and testing them became much harder than the ones we implemented in the past we started to investigate the existing design. And if we found a better way how to organize our application we adjusted the architecture accordingly. Some of the biggest changes we made in our application was when we switched from Model View Presenter (MVP) pattern to Model View View Model (MVVM) and upgraded Dagger to the latest version. The other lesson we learned was, there might be cases when there isn’t only one good solution. That was the case when we were designing the database and data access layer in our Android app. We had several options like:

  • Room
  • Squidb
  • Sqlbrite

We were not sure which would fit better in our design and even now we think any of them would work well in our application.

At the time we started to design our application Android didn’t have yet Architecture Components nor Guide to App Architecture, so we had to start somewhere else but eventually we arrived to almost the same architecture model as suggested here https://developer.android.com/jetpack/docs/guide

Contrary to ASP.NET Core (we use it for our back end) where developer can choose a project template in Visual Studio and start to work with well established patterns just by extending the template, in Android world we had to create the project structure by ourselves by choosing the most appropriate technologies and architectural patterns. Nowdays you can start with Architecture Components and recommended app architecture (https://developer.android.com/jetpack/docs/guide), since most likely it will become most common way how to build complex applications in Android. But this is just a reference model – the backbone, base – where we can start to add our first classes. The next step was to extend our backbone in such way that we could keep avoiding pitfalls and shortcomings of poor design (the things I mentioned in the beginning). And this is the place where the classic Object Oriented Programming skills come in to play. First to make it easy to extend our application with new features we applied SOLID principles. Where S stands for Single-responsibility principle, O – Open-closed principle, L – Liskov substitution principle, I – Interface segregation principle, D – Dependency Inversion Principle. Next when we noticed technologies that allowed us to follow these principles we included it in our project. For example Dagger was one of such libraries that allowed us to follow Dependency Inversion Principle and Android data binding library was another one that made it easier to follow Single responsibility principle. Once we started to apply SOLID principles we were able to identify the standard design patterns in our application code and so we started to organize the parts of the code around the design patterns (https://www.geeksforgeeks.org/software-design-patterns/).

To make a good architecture for complex application is not an easy task. It requires experience, good understanding of Object Oriented programming and knowledge of technologies in platform you are developing for.

The way to data binding in Android

Today I wanted to share our experience on the way to MVVM (Model View View Model) pattern in Android project.

When the data binding library was introduced at Google I/O in 2015, it looked very promising technology and very awaited in our team. We have developers who developed in the past Windows applications using .NET framework using MVVM framework. They loved that pattern. And there were good reasons for it:

  • MVVM gives a clean separation between the UI and the rest of the application. Although it is still possible to bring the business logic in to the UI, because of powerful data binding expressions, but now the framework is on developers side to keep the things separate. And in most cases it is only up to developers to produce a clean code.

  • it improves test-ability. More code from UI is moved to easy testable View Model classes

  • it allows to work independently on UI and business parts. And such responsibility delegation becomes more clearer

But until 2015 MVVM was available mostly for Windows application developers, because it turns out that in order to implement MVVM pattern we know it now we need UI markup language and data binding expressions. Without these two components most common patterns developers were left with were MVP(Model–view–presenter) and MVC(Model–view–controller). In the web world things progressed faster, since already from the very beginning the main way how to create the UI was markup language (HTML) and some time later dynamic web emerged and along the way different engines that allowed developers merge data with the markup. But in the desktop and mobile application world markup languages and data bindings emerged only recently. First Microsoft introduced WPF (Windows Presentation Foundation) subsystem with XAML as a part of .NET framework. And later came out Android with its own markup language. About the same time when WPF was announced Microsoft architects Ken Cooper and Ted Peters announced MVVM pattern on their blog. And so MVVM era started in the Windows world, but Android developers had to wait little bit, before they could start to use MVVM framework.

So when the Android data binding (https://developer.android.com/topic/libraries/data-binding/index.html) and Architecture components (https://developer.android.com/topic/libraries/architecture/adding-components.html) were released, we decided to  give it a try. Until then we were already striving to separate UI from the rest of the application and therefore we were using MVP pattern in combination with Butter knife (http://jakewharton.github.io/butterknife/). And the first thing we noticed is that we don’t have to write so much boilerplate code to keep the UI and business logic separate. Now instead of Presenter, View interface and Activity that implements the View we wrote very thin Activity and Model View and made slight changes in layout files. So some of the user stories we could write faster. But it was not always the case. When we had to work with more complex views like map view we could not bind the data directly in the layout file, because of the lack of bindings. And so data binding was done in the Activity or Fragment. But from our perspective it was still  step forward because most of the views we used had bindings and if they didn’t we could implement simple Binding Adapters. Essentially we started to use data binding in layout markup where it was easy to use it and left the UI processing code in Activity or Fragment where it will have taken a lot of time to find a way how to implement the binding for the layout markup. So for our project MVVM worked out very well, but we should admit that there are projects where it will not bring much advantage. Therefore before you take a decision about the using of MVVM and data binding spend some time to investigate views and available bindings for them you are going to use in a project.
